EQUIPMENT FEATURES
Interface 1× 10M/100M/1000Mbps Gigabit Ethernet Port (RJ45); PoE in
1× Grounding Termina
1× Reset button: Press the button for longer than 5 seconds to make the device restore to factory settings.
Power Supply Input: 802.3at PoE+: 42.5 - 57 V, 0.36A
Power Consumption 802.3at (PoE+): 15.8w, 2.4GHz radio 2×2, 5GHz radio 2×2, wired link rate can be up
to 1 Gbps, etc.
Idle mode: 4.8W(PoE)
Dimensions (W × L × H) Main Unit: 230 × 207.5 × 69.7 mm (9.06 × 8.17 × 2.74 in. )
Shipping Unit: 324 × 104 × 245 mm (12.76 × 4.09 × 9.65 in. )
Wi-Fi Antenna
2.4 GHz: 2 × 4 dBi (peak gain), external omnidirectional antennas
5 GHz: 2 × 5 dBi (peak gain), external omnidirectional antennas
*Note: The gains above are the single-antenna peak gains.

IoT
Bluetooth: 1 × 4 dBi (peak gain), internal omnidirectional
antennas
Bluetooth Yes
IP66 for Wall Mount Weatherproof Enclosure
IP65 for Pole Mount
Mounting Pole Mount (Kits included)
Wall Mount (Kits included)
WIRELESS FEATURES
Maximum coverage area 2.4 GHz: up to 2,150 ft (200 m)
5 GHz: up to 3,200 ft (300 m)
5 GHz wireless network standards: IEEE 802.11a/n/ac/ax
2.4 GHz: IEEE 802.11b/g/n/ax
Frequency 5 GHz
2.4 GHz
Signal speed 2.4 GHz: up to 573 Mbps
5 GHz: up to 1201 Mbps
*Note: Country-Specific Restriction Apply
Wireless Network Features Maximum number of BSSIDs: 16 (8 on each band)
Maximum number of associated STAs: 250+
Guest Network
ACS (Automatic Channel Selection)
Airtime Fairness
Band Steering
802.11 Rate Control
Rogue AP Detection
URL Filtering
WLAN Optimization
Lock to AP
SSID/Client Rate Limit
Load Balance
Seamless Roaming (802.11k/v/r, Non-Stick Roaming, Ping-Pong Roaming Suppression, AI Roaming)§
Multicast/Broadcast Management (Multicast-to-Unicast Conversion, ARP-to-Unicast Conversation, Multicast Filtering, Multicast/Broadcast Rate Limit)
QoS (Quality of Service)
Wireless Network Security ACL
MAC Filter
802.1X Authentication
MAC-Based Authentication
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, Enhanced Open, and None
Radius Accounting
PPSK without Radius, PPSK with Radius (Generic Radius with bound MAC/EKMS/Generic Radius with unbound MAC)
Captive Portal: No Authentication, Simple Password, Hotspot (Voucher / Local User / SMS / RADIUS / Form Auth), RADIUS Server, External LDAP Server, External Portal Server, Pre-Authentication Access, and Authentication-Free Client
EAP Types: EAP-TLS, EAP-TTLS, EAP-PEAP, EAP-CHAP, EAP-SIM, EAP-AKA, EAP-GTC, EAP-FAST, EAP-PEAP, EAP-MD5, EAP-MSCHAPv2, PEAPv0, PEAPv1
Maximum transmit power:
CE (ERIP)
2.4 GHz: 20 dBm
5 GHz: 23 dBm in U-NII-1, 23 dBm in U-NII-2A, 29 dBm in U-NII-2C,
FCC (Conducted Power)
2.4 GHz: 25 dBm
5 GHz: 27 dBm in U-NII-1, 24 dBm in U-NII-2A, 24 dBm in U-NII-2C, 27 dBm in U-NII-3

Minimum transmit power
CE (ERIP)
2.4 GHz: 7 dBm
5 GHz: 6 dBm in U-NII-1, 6 dBm in
